A TRUE SPEED MISSILE, READY TO LAY DOWN THE HURT

The IA 2.0 is the fastest triathlon platform Felt has ever created and is now available with the crowd-favorite, Shimano Ultegra Di2 component groupset. 12-speeds, wireless-shifting, and dialed for performance, this component set-up delivers massive benefits for those seeking the next step on the podium. Fully kitted out with Shimano R8170 C60 wheels, this is your new ticket to speed.

FRAMESET

• FRAMEFelt IA 2.0, UHC Ultimate + TeXtreme carbon
• FORKFelt IntegratedAero Disc 2.0, UHC Ultimate + TeXtreme carbon

BRAKES & DRIVETRAIN

• FRONT BRAKEShimano BR-R9170, 2-piston, Hydraulic disc brake
• FRONT BRAKE ROTORShimano RT-MT800, 140 mm, Center lock
• REAR BRAKEShimano BR-R9170, 2-piston, Hydraulic disc brake
• REAR BRAKE ROTORShimano RT-MT800, 140 mm, Center lock
• BRAKE LEVERShimano Dura Ace Di2 ST-R9180
• REAR DERAILLEURShimano Ultegra Di2, RD-R8150, Shadow, 24-S
• FRONT DERAILLEURShimano Ultegra Di2, FD-R8150
• CASSETTEShimano CS-R8100, 11-30 T
• CHAINShimano CN-M8100
• CRANKSETShimano Ultegra, FC-R8100, 52/36 T
• SHIFT LEVERShimano Dura-Ace Di2, ST-R9180

WHEELS

• WHEELSETShimano Ultegra, WH-R8170, Tubeless ready
• TIREContinental Grand Prix 5000, 700x25

COCKPIT

• HEADSETIS (IS-2)
• HANDLEBARAerobar-Stem-Combination: Felt Dagger Direct 2.0 ASC / Extensions: Devox Ergomod | carbon fiber
• BAR TAPEFelt EVA arm pads with anti-microbial cover and Felt Gel tape
• SADDLEISM PS1.0, Satin Steel
• SEAT POSTFelt Aero TRI IL 2.0 VM

ADDITIONAL INFORMATION

• PERMISSIBLE TOTAL WEIGHT129kg
• TRAILER APPROVALNo trailer approval



SIZE GUIDE

	47	48	51	54	56	58
RIDER HEIGHT	152.4 - 167.6 cm 5’0” - 5’5”	152.4 - 167.6 cm 5’0” - 5’5”	167.6 - 172.7 cm 5’5” - 5’8”	172.7 - 180.3 cm 5’8” - 5’11”	180.3 - 187.9 cm 5’11” - 6’2”	187.9 - 195.5 cm 6’2” - 6’5”
RIDER INSEAM Measured from crotch to floor.	70.8 - 74.4 cm 27.9” - 29.3”	70.8 - 74.4 cm 27.9” - 29.3”	74.4 - 77.9 cm 29.3” - 30.7”	77.9 - 83.0 cm 30.7” - 32.7”	83.0 - 85.8 cm 32.7” - 33.8”	85.8 - 88.9 cm 32.7” - 35.0”

GEOMETRY

	48	51	54	56	58
(A) Top Tube Length	468 mm	486 mm	510 mm	541 mm	573 mm
(B) Seat Tube Length	496 mm	525 mm	546 mm	571 mm	598 mm
(C) Seat Tube Angle	79.5 °	79 °	78.5 °	78 °	77.5 °
(D) Head Tube Length	67.5 mm	96 mm	111 mm	136 mm	163 mm
(E) Steering Angle	71.5 °	71.5 °	72 °	72 °	72 °
(F) Chain Stay Length	405 mm	405 mm	405 mm	405 mm	405 mm
(G) Wheel Base	970 mm	987 mm	1000 mm	1029 mm	1058 mm
(H) Standover Height	735 mm	749 mm	765 mm	779 mm	793 mm
(I) BB-Drop	72 mm	72 mm	72 mm	72 mm	72 mm
(K) Fork Offset	50 mm	50 mm	45 mm	45 mm	45 mm
(L) Stack	478 mm	505 mm	522 mm	546 mm	572 mm
(M) Reach	379 mm	387 mm	404 mm	425 mm	445 mm
(O) Crank Length	165 mm	165 mm	170 mm	170 mm	172.5 mm
